TEMPERATURE CONTROL

This laboratory is designed for the study of the temperature control application to allow the student a practical training, based on the performance of guided experiments.

Industrial type components are educationally adapted by using a modular panel system to permit the step by step assembling from the simplest circuit to the most complex system.

• With this laboratory it is possible to perform the following experiments:
• The two position controller in the temperature process
• The two position controller with delayed feedback in the temperature process
• The two position controller with elastic feedback in the temperature process
• The three range controller in the temperature process
• P, PI and PID controls of the temperature process using the CHR method The laboratory is supplied complete with a theoretical and practical manual.
