LOGIC CIRCUITS

The design and construction of electronic circuits to solve practical problems is an essential technique in the fields of electronic engineering and computer engineering.

With this board the students can study the fundamentals of digital logic, the theorems of Boolean algebra, the combinatory networks, the karnaugh’s maps, encoders and decoders, multiplexers and demultiplexers and the characteristics of the logic families of TTL and CMOS.
